1 - 2007 Mori Seiki NT3200 CNC lathe
Norsborg | Svezia
Combination 1, 108-111, 240, 462 | Lavorazione dei metalli - Torni CNC
50.000,00 SEK
4 - 2017 DMG Mori NTX 1000 CNC mill-turn center
Rümlang | CH
Offerta iniziale
Offerta attuale
Offerta finale
125.000,00 €
0
Offri
Offerte
Maggior offerente
Superato
La mia ultima offerta: 0,00 € (Offerta automatica)
Condividere
Informazioni sul prodotto
| Marchio | DMG Mori |
| Type | NTX 1000 |
| Year | 2017 |
| Amount | 1 |
Operating hours: 16724
Maximum turning diameter: 450mm;
Maximum turning length: 800mm;
X1/X2-axis travel: 455/160mm;
Y-axis travel: +/-105mm;
Z1/Z2-axis travel: 800/730mm;
B-axis capacity: +/-120°;
Maximum spindle 1/2 speed: 5.000/6.000 rpm;
Spindle 1/2 head: JIS A2-6/JIS A2-5;
Spindle 1/2 bore: 73/61mm
Milling spindle speed: 12.000 rpm;
Toolholder type: C5
Toolholder magazine capacity: 2x 38
Turret capacity: 10
Driven tool speed on turret: 10.000 rpm
Machine weight: 12.000 kg
Equipped with: LTA oil mist separator, Kraft & Bauer fire extinguish insulation, Knoll coolant filter, Hyfra cooler, parts catcher, spare parts and documentation
Informazioni aggiuntive
Pickup within October and by appointment only. After the auction a detailed pickup schedule with dates and more information will be shared with all buyers. Selected service partner is Bollhalder Industrielogistik AG who is responsible for the proper dismantling and loading of lots onto the transport of the buyer. The costs for this mandatory service are shown per lot as 'Additional costs' and will be added to your bid. Lot numbers above 200 are already properly dismantled by and stored at the company Bollhalder (viewing and pickup by appointment only).
Operating hours: 16724
Maximum turning diameter: 450mm;
Maximum turning length: 800mm;
X1/X2-axis travel: 455/160mm;
Y-axis travel: +/-105mm;
Z1/Z2-axis travel: 800/730mm;
B-axis capacity: +/-120°;
Maximum spindle 1/2 speed: 5.000/6.000 rpm;
Spindle 1/2 head: JIS A2-6/JIS A2-5;
Spindle 1/2 bore: 73/61mm
Milling spindle speed: 12.000 rpm;
Toolholder type: C5
Toolholder magazine capacity: 2x 38
Turret capacity: 10
Driven tool speed on turret: 10.000 rpm
Machine weight: 12.000 kg
Equipped with: LTA oil mist separator, Kraft & Bauer fire extinguish insulation, Knoll coolant filter, Hyfra cooler, parts catcher, spare parts and documentation
