26 - 1965 SASS TRL 1600 Radial Drilling Machine
Venaria Reale | IT
Puja inicial
Puja actual
Puja final
500,00 €
0
Pujar
Pujas
Mayor postor
Superado
Mi última puja: 0,00 € (Puja automática)
Compartir
Información del producto
| Marca | SASS |
| Type | TRL 1600 |
| Year | 1965 |
| Serial number | 1300 |
| Amount | 1 |
RADIAL DRILL SASS mod. TRL 1600
Drilling/tapping in steel diameter mm 50
Quill taper CM 5
Vertical quill travel mm 400
Sliding quill travel mm 85
16 rotation speed values rpm 32 ÷ 1945
Max. reach (column center to spindle axis) mm 1.600
Head movement along arm mm 1.295
Vertical arm movement mm 810
Min. max. height (spindle nose to base plate) mm 390 - 1.600
Column diameter mm 380
Approximate net weight Kg 4.500
Complete with:
- Hub
Información importante
All buyers will be informed within 48 hours after the auction closure about their actual pick-up day being in week 18 &19.
RADIAL DRILL SASS mod. TRL 1600
Drilling/tapping in steel diameter mm 50
Quill taper CM 5
Vertical quill travel mm 400
Sliding quill travel mm 85
16 rotation speed values rpm 32 ÷ 1945
Max. reach (column center to spindle axis) mm 1.600
Head movement along arm mm 1.295
Vertical arm movement mm 810
Min. max. height (spindle nose to base plate) mm 390 - 1.600
Column diameter mm 380
Approximate net weight Kg 4.500
Complete with:
- Hub
